Description BEE STAR RATING 4 STAR COMPRESSOR TYPE Super Tropical – Rotary REFRIGERANT  VOLUME CONTROL USING Dual Capilary Expansion POWER SOURCE 1 PHASE, 230 V, 50 HZ RATED COOLING CAPACITY AT 100% 23458 RATED COOLING CAPACITY AT 50% Not Applicable for Fixed Speed Ac RATED COOLING CAPACITY AT 100% 6875 RATED COOLING CAPACITY AT 50% Not Applicable for Fixed Speed Ac RATER POWER CONSUMPTION AT 100% Watts 1635 RATER POWER CONSUMPTION AT 50% Not Applicable for Fixed Speed Ac RATED EER / COP AT 100% W/w 4.2 RATED EER / COP AT 50% Not Applicable for Fixed Speed Ac RATED INDIAN SEASONAL ENERGY EFFICIENCY ISEER 4.2 INPUT POWER ( MINIMUM – MAXIMUM ) Watts 1385 ~ 1635 CURRENT ( MINIMUM – MAXIMUM ) A 6.2 ~ 7.3 DIMENSION ( H * W * D ) INDOOR UNIT mm 339 X 1197 X 262 OUTDOOR UNIT mm 750 X 880 X ( 88) X 340 WEIGHT INDOOR UNIT Kgs 17 OUTDOOR UNIT Kgs 63.5 AIR FLOW ( CMH ) INDOOR UNIT m /hr 1400 LONG REACH AIRFLOW UPTO INDOOR UNIT Feet 18.29 SOUND LEVEL ( H /M/ L ) INDOOR UNIT Db 47/43/40 LOUVER SWING INDOOR UNIT 3D 3D AUTO SPECIAL FILTER INDOOR UNIT Natural Enzyme Photocatalytic deodizing Filter Anti Bacterial  BLOWER FAN INDOOR UNIT Anti – Micro Bial Fan DC FAN MOTOR SPEED INDOOR UNIT Auto / Powerful / High /Med /Low / Dry REFRIGERANT R410A REFRIGERANT PIPING THICKNESS : 18 GAUGE ( 1mm ) LIQUID LINE mm 6.35 ( 1 / 4″ ) GAS LINE mm 15.88 (5/8″) MAIN POWER SUPPLY TO OUTDOOR UNIT 2.5 mm  2*3 cores (With Earthing Cable) CONNECTING WIRING B / W IDU & ODU 2.5 mm  2*4 cores (With Earthing Cable) AREA COVERAGE*** Sq.Meters 27.88~37.17
